| Size | PR | Standard Rim | Load index | Load Capacity(KG) | Pressure(Kpa) | Tread Depth (mm) |
Speed Rating |
Inflated tyre Dimension (mm) | |||
| Single | Dual | Single | Dual | Overall Diameter |
Section Width | ||||||
| 11R22.5 | 16 | 8.25 | 146/143 | 3000 | 2725 | 830 | 830 | 15.0 | M | 1048 | 273 |
| 12R22.5 | 18 | 9.00 | 152/149 | 3550 | 3250 | 930 | 930 | 15.0 | M | 1081 | 292.1 |
| 295/80R22.5 | 18 | 9.00 | 152/149 | 3550 | 3250 | 900 | 900 | 15.0 | M | 1041 | 292 |
| 315/80R22.5 | 18 | 9.00 | 154/151 | 3750 | 3450 | 830 | 830 | 15.0 | M | 1078 | 310 |
| 315/80R22.5 | 20 | 9.00 | 156/150 | 4000 | 3350 | 850 | 830 | 15.0 | L | 1078 | 310 |
