| Size | PR | Standard Rim | Load index | Load Capacity(KG) | Pressure(Kpa) | Tread Depth (mm) |
Speed Rating |
Inflated tyre Dimension (mm) | |||
| Single | Dual | Single | Dual | Overall Diameter |
Section Width | ||||||
| 11R22.5 | 16 | 8.25 | 146/143 | 3000 | 2725 | 830 | 830 | 15.0 | M | 1048 | 273 |
| 12R22.5 | 18 | 9.00 | 152/149 | 3550 | 3250 | 930 | 930 | 15.5 | M | 1082 | 292.1 |
| 11R24.5 | 16 | 8.25 | 149/146 | 3250 | 3000 | 830 | 830 | 15.0 | K | 1100 | 273 |
| 13R22.5 | 18 | 9.75 | 154/151 | 3750 | 3450 | 830 | 830 | 15.5 | M | 1119 | 315 |
