| Size | PR | Standard Rim | Load index | Load Capacity(KG) | Pressure(Kpa) | Tread Depth (mm) |
Speed Rating |
Inflated tyre Dimension (mm) | |||
| Single | Dual | Single | Dual | Overall Diameter |
Section Width | ||||||
| 7.00R16LT | 14 | 5.50F | 118/114 | 1320 | 1180 | 770 | 770 | 14.5 | L | 774 | 196 |
| 7.50R16LT | 14 | 6.00G | 122/118 | 1500 | 1320 | 770 | 770 | 15.0 | L | 806 | 210 |
| 8.25R16LT | 16 | 6.50H | 128/124 | 1800 | 1600 | 770 | 700 | 15.5 | L | 858 | 230 |
| 9.00R20 | 16 | 7.0 | 144/142 | 2800 | 2650 | 900 | 900 | 17.5 | K | 1022 | 260 |
| 10.00R20 | 18 | 7.5 | 149/146 | 3250 | 3000 | 930 | 930 | 19.0 | K | 1055 | 276 |
| 11.00R20 | 18 | 8.0 | 152/149 | 3550 | 3250 | 930 | 930 | 19.5 | K | 1089 | 288 |
| 12.00R20 | 20 | 8.5 | 156/153 | 4000 | 3650 | 900 | 900 | 21.5 | K | 1127 | 310 |
