| Size | PR | Standard Rim | Load index | Load Capacity(KG) | Pressure(Kpa) | Tread Depth (mm) |
Speed Rating |
Inflated tyre Dimension (mm) | |||
| Single | Dual | Single | Dual | Overall Diameter |
Section Width | ||||||
| 10.00R20 | 18 | 7.5 | 149/146 | 3250 | 3000 | 930 | 930 | 16.0 | K | 1049 | 276 |
| 11.00R20 | 18 | 8.0 | 152/149 | 3550 | 3250 | 930 | 930 | 16.5 | K | 1083 | 288 |
| 12.00R20 | 20 | 8.5 | 156/153 | 4000 | 3650 | 900 | 900 | 17.0 | K | 1119 | 310 |
| 12.00R24 | 20 | 8.5 | 160/157 | 4500 | 4125 | 900 | 900 | 16.0 | K | 1215 | 316 |
